To release the retainer lock on the shift cable, insert a wide blade screwdriver to spread the ears.
The axles should be installed before adding fluid to the gear box or it will flow out when the level reaches the axle drive.
The boiling point of gasoline at 1 atmospheric pressure can vary between 100 and 400 Fahrenheit depending upon additive content. Fuel in the R53...
To keep the flywheel from turning while applying torque, a pry bar can be used to brace against a starter ring-gear tooth.
The bolt index mark aligned with the final angle mark.
The R56 flywheel bolts require two torque stages 8ft-lb and 22ft-lb, followed by a 90 degree torque angle. A torque angle meter/gauge can be used...
In addition to two E-12 Torx bolts securing the starter on the back side of an R56 bell housing, there is one 13mm hex head on the front.
A deep 9/16ths socket fits the clutch disc and crankshaft bore, with an extension on the end it can be used in lieu of a conventional alignment tool.
The alignment pin fits through this hole in the case from the outside.
The alignment pin for holding the crankshaft at 90 degrees BTDC fits in this hole.
The R56 crankshaft dowel fits here.
This dowel fits in a hole on the back of the R56 flywheel.
The R56 has T-55 size flywheel bolts, T-50 is the largest inner bit size most kits have.
SPC control arms. The sub frame cannot be moved because of the dowel cones.
The sub frame has indexing dowels up front, so no way to adjust that orientation. Be sure the front shocks are inserted all the way in the...
Best value and fit, JCW rear anti-sway bar BMW OEM Part 33556782723 - Stabilizer, rear Genuine OEM Parts available from DDM and OEM Teflon...
Tape measure, painter's tape, Sharpie, drill bit, hole saw, box cutter, files, sand paper. The bumper cover behind the trim was also cut to...
